5754 aluminum plate

What is 5754 aluminum plate?

AW5754 aluminum alloy is a non-heat treatable aluminum alloy in the 5000 series Al-Mg (aluminium-magnesium) family. It is known for its excellent tread and anodized quality, weldability and corrosion resistance, its excellent machinability, corrosion resistance, high fatigue strength, high weldability and moderate static strength. So commonly used in tanker trucks.

Specification of 5754 aluminum plate

Alloy	AW5754	Temper:	O,F,H12,H14,H22,H24,H111,H112,H114,etc
Application:	Fuel tanker truck	Type:	hot rolled,cold rolled,checkered plate,diamond pattern plates,etc
Thickness	2-8mm	Standard:	GB/T, ASTMB209, EN573, EN485
Width:	1000-2000	Length:	As clients’ requests
Certificate:	CE, ISO9001	Grade:	5000 Series
Processing Service:	Welding, Punching, Cutting, Bending, Decoiling	Laminating type:	blue film, electrostatic blue film transparent film, black and white film, laser film, paper clip, stamping film, stretch film
Manufacture process	Direct casting(DC) Continuous casting(CC)	Finish	Mill finish,Polish,ect

Mechanical property of AL5754

Alloy	Temper	Thickness(mm)	Tensile Strength(Mpa)	Yield Strength(Mpa)	Elongation(%)
5754	O/H111	1.5-3	190-240	≥80	≥16
5754	O/H111	3-6	190-240	≥80	≥18

Why is the 5754 aluminum plate suitable for tank trucks?

1. Tanker trucks must have a high degree of leak-proof performance to prevent leakage of liquid goods, so the processing performance of the material can be weldable has high requirements.

2. For tanker,both internal and external materials must have sufficient corrosion resistance to resist the transportation of liquid goods may produce corrosion. This and other systems and steel plate compared to 5754 aluminum plate has a higher corrosion resistance.

3. Aluminium plate is lightweight, and steel plate, the weight is lighter so it will be more fuel-efficient to save costs.

4. The aluminum alloy has good electrical conductivity, when a tanker truck collision occurs, the static electricity accumulates on the tank body very little, and therefore does not produce sparks, thereby reducing the occurrence of explosions and other accidents.

Package

Our packing for 5754 aluminum plate meets the sea export standard.
PE/PVC protective film or white paper could be covered as customer’s need.
Special requirements of packing could be negotiate before order.
